Gerber DCS 1500 Cutting Machine Parts & Supplies

Parts list for Theta Axis Assembly (A-CR2-188)
We recommend that the following parts be purchased as a complete assembly and not as individual parts.
Refer to Table 2-1.

PART NUMBER DESCRIPTION QTY. UNITS
A-CR2-194        T-AX DRIVE MOTOR ASSY. CE
A-CR2-251       CYLINDER ASSY, HEAVY DUTY
A-CR2-252       HEAVY DUTY SENSOR ASSEMBLY, TOOL 1
A-CR2-253       HEAVY DUTY SENSOR ASSEMBLY, TOOL 2
A-CR2-254       HEAVY DUTY SENSOR ASSEMBLY, TOOL 3
A-CR2-300      HUB, ASSY, CYLINDER, T-AX, CES
CB2-056 3       POS CONN, RECEPTACLE AMPMODU MTE 22-26A
CR-015             WOODRUFF KEY
CR-051             ELBOW, TUBING, 1/8NPT X 1/4, CES (NOT SHOWN)
